NCH8 2-Pole Modular AC Contactor, 20A or 25A

A compact modular contactor that clips onto DIN rail in a distribution board and switches a load on and off from a remote control signal. Two normally open power poles sit above and below the body, with the coil terminals marked A1 and A2 on the front face. The coil runs on 220 to 230V AC at 50 or 60Hz, and the housing is rated IP20 for use inside an enclosure. A terminal diagram is printed on the front so wiring can be checked without the datasheet. Two ratings are offered, the NCH8-20/20 at 20A and the NCH8-25/20 at 25A. • Two normally open poles in a DIN rail modular body • 220 to 230V AC coil at 50 or 60Hz, marked A1 and A2 • Terminal diagram printed on the front face • NCH8-20/20 rated 20A or NCH8-25/20 rated 25A Please note: • Installation and circuit selection should be completed by a qualified electrician. • Confirm the coil voltage, utilization category and load rating before installation. • IP20 equipment should be installed in a suitable protective electrical enclosure. Package contents: • 1 × selected modular AC contactor Estimated delivery: 50 days after payment · Priority Shipping available: 5 days after payment

Image text in English

• CHINT; NCH8-20/20; NCH8-25/20; AC contactor.
